17 Inch RK3566 IP65 Lcd Panel Pc Wall Mount Android Industrial Panel Pc
This 17 -inch Android industrial tablet has a strong performance. The high -definition screen has greatly improved the user experience. Equipped with RK3568 processor to provide efficient task processing capabilities. The 17-inch large screen with 1080P resolution can provide high -definition visual experience, suitable for complex industrial interface display. Using multiple interfaces, strong scalability. IP65 level dustproof and waterproof can be used in a harsh industrial environment. Capacitor touch screen, supports multiple touch, is more sensitive.
- Video
- Features
- Parameter
- Products Description
- Packaging
- Recommended Products
Video
Packaging support customization, users can customize logo tags on the box. Customized packaging can be customized according to the different needs of the user.
Features
- Panel: 17"LCD panel
- CPU:RK3566
- RAM:2/4/8GB
- Memory:16/32/64/128GB
- Resolution:1920x1080
- System:Android 12
Tablet Key Features
Parameter
| System | |
| CPU | RK3566 Quad Core Cortex-A55 |
| RAM | 2GB |
| ROM | 16GB |
| Operation system | Android 12 |
| Display | |
| Size | 17 inch |
| Panel | LCD |
| LED backlight | lifetime>25000 hours |
| Resolution | 1920X1080 |
| Defend degree | IP65 |
| Touch Screen | Capacitive Touch |
| Network | |
| Network Port | Optional |
| Wireless WIFI | Support |
| Bluetooth | Support |
| Interface | |
| HDMI | 1 channel HDMI interface （optional） |
| RS-232 | 4 channel 3 wire RS-232 serial port（COM1、COM2、COM3、COM7） |
| USB | 2 channel USB Host interface ,support usual USB device such as mouse, keyboard, U disk, etc. |
| Ethernet | 1 channel 1000M Ethernet interface (The second network port is optional) |
| SD/MMC | 1 channel SD/MMC interface ,support SD card and MMC card |
| TYPE-C | 1 channel TYPE-C interface ,support ADB connect to PC to exchange date and debug application . |
| Other | |
| Power consumption | DC 12V /3A |
| Working temperature | -10~50℃ |
| Storage temperature | -20~60℃ |
| Shell structure | front plastic+back metal |
Products Description
17Inch screen
Use a large 17-inch screen to provide sufficient large display areas to show more information. Very suitable for use in the industrial environment. Large screens can show more windows and improve work efficiency. Can show more details, users use better effects.
IP65 Working temperature
IP65 dustproof waterproof can be used in the large industrial environment. With a certain ability of underwater operation, the equipment is more durable. The operating temperature supports-20 ° C to 60 ° C is suitable for use in extreme temperature environments, and the use scenarios are wider.
1080P Resolution
Use 1920x1080 HD resolution. With a large 17 -inch screen, it can provide clear visual effects, and users can view data, images or videos more intuitively. Reduce eye fatigue, and the user's visual experience is better.
RK3566 CPU
RK3566 uses a 64-bit quad-core ARM Cortex-A55 CPU, which provides sufficient performance to handle conventional meetings. RK3566 supports 4K video decoding and output, which is very useful for the conference scene that requires high -definition display or video playback. It can provide clear image quality, and its energy efficiency ratio is very high, which extend the battery life of the equipment.
10-Point touch
The use of 10 -point capacitor touch has high precision and high sensitivity, which can accurately identify the user's touch position and action, reduce the chance of misunderstanding, improve the accuracy of the operation, and better experience the user experience.
Android12 system
Using Android 12 system, high performance, improve the overall fluency and response speed of the equipment, especially suitable for multi -tasking processing and resource -intensive applications. Android 12 optimizes multi -tasking view and division of operation. Users can switch and operate between multiple applications smoother, suitable for industrial scenarios that need to view multiple data sources at the same time.
24Hours working time
The industrial panel PC is robust and durable, designed for uninterrupted operation 24/7,with a lifespan of 50,000 hours for the entire machine.
Multi interface
Provides interfaces such as HDMI, Lan, USB, COM, audio, and RS232/485. It is suitable for connecting various peripherals, strong scalability, suitable for industrial Internet of Things, data collection and other applications.
Packaging
Packaging support customization, users can customize logo tags on the box. Customized packaging can be customized according to the different needs of the user.
