13.3Inch POE NFC Room Booking Systems Wall Mounted Conference Android Tablet For Meeting

This device uses a 13.3 -inch screen with NFC and POE functions to make the device function more powerful. Use RK3566 processor and Android 11 system to bring users a smooth operating experience. Support custom memory to meet the different needs of users.This device uses a design without light bar, the equipment is more power -saving, the equipment can work longer.

Video
Features
Parameter
Products Description
Packaging
Recommended Products

Video

Features

Tablet Key Features

1.CPU:RK3566

2.RAM/ROM:2+16GB

3.System:Android 11

4.Touch Panel:10-Point Capacitive Touch

5.POE function optional

6.Resolution:1920x1080

Parameter

System
CPU	RK3566 Quad core cortex A55
RAM	2GB
Internal memory	16GB
Operation system	Android 11
Touch screen	10-Point capacitive touch
Display
Panel	13.3 "high-definition full view screen
Resolution	1920x1080
Display mode	Normally black
Viewing angle	85/85/85/85(L/R/U/D)
Contrast ratio	800
Luminance	250cd/m2
Aspect Ratio	16:9
Network
WiFi	802.11b/g/n/a/ac/ax
Ethernet	100M/1000M ethernet
Buletooth	Bluetooth 4.0
Interface
TF Card	TF card,Max Support to 64GB
USB	USB host
USB	USB for serial ( RS232 Level),Optional for USB Host
Type-c	Used for external devices and data transmission
RJ45	Ethernet interface ( POE function standard IEEE802.3at,POE+,class 4， 25.5W )
Power jack	DC power supply 12V input
Earphone	3.5mm earphone + Micphone
Media play
Video format	MPEG-1,MPEG-2,MPEG-4,H.265,H.264,VC-1,VP8, etc.,support up to 4K
Audio format	MP3/WMA/AAC etc.
Photo	jpeg
Other
VESA	75x75mm
Speaker	2*2W
Microphone	Dual microphone
Camera	5 million from a conventional perspective
Working temp	0--40degree
Certificates	CE/FCC
Language	Multi-language
Accessories
Adapter	Adapter,12V/1.5A
User manual	yes

Products Description

13.3inch screen

13.3 -inch is an ideal size, which is large enough to provide a good visual experience, but it is small enough to carry and operate. It can be easily placed on the conference table or backpack, suitable for situations that need to be used in different places.

RK3566 CPU

RK3566 uses a 64-bit quad-core ARM Cortex-A55 CPU, which provides sufficient performance to handle conventional meetings. RK3566 supports 4K video decoding and output, which is very useful for the conference scene that requires high -definition display or video playback. It can provide clear image quality, and its energy efficiency ratio is very high, which extend the battery life of the equipment.

RK3566 4+64GB.jpg

1920x1080 Resolution

The 1080P resolution screen can provide good display effects on different sizes of tablets. It can display clear content on the small screen, or maintain proper pixel density on large screens. When using the screen sharing function, the resolution of 1080P can ensure that the shared image remains good quality. Even remote participants can see clear display content, which is very suitable for conference tablet use.

stand by me tv 1080p(35e13e965e).jpg

10-Point Capacitive touch

Support 10 -point capacitor touch, the response is faster, the touch is more sensitive, the customer's experience is better. Customers can query the meeting time arrangement by touching the screen to increase the customer's experience.

10 inch tablet.jpg

Android System

Using the Android 11 system, with stricter privacy and security control, access requests for sensitive permissions (locations, microphones, cameras, etc.) are more transparent. Users can better control the authority of the application and improve the security of the tablet.

stand by me tv android 12system(2a3973355b).jpg room scheduler.jpg

Packaging

Packaging support customization, users can customize logo tags on the box. Customized packaging can be customized according to the different needs of the user.

Tablet packing.jpg
